Electric vehicles with bidirectional charging capabilities could be used to power homes, feed energy back into the grid, and even provide backup power during power outages or emergencies. Electric vehicles are essentially large batteries on wheels, so bidirectional chargers allow vehicles to store inexpensive off-peak electricity, reducing household electricity costs. This emerging technology, known as vehicle-to-grid (V2G), has the potential to revolutionize how our power grid operates, with tens of thousands of electric vehicles potentially providing power simultaneously during peak demand periods.
How does it work?
A bidirectional charger is an advanced electric vehicle (EV) charger capable of charging in both directions. This may sound relatively simple, but it involves a complex power conversion process from alternating current (AC) to direct current (DC), unlike a conventional unidirectional EV charger that uses AC.
Unlike standard EV chargers, bidirectional chargers work much like inverters, converting AC to DC during charging and vice versa during discharging. However, bidirectional chargers can only be used with vehicles compatible with bidirectional DC charging. Unfortunately, the number of EVs currently capable of bidirectional charging is very small. Because bidirectional chargers are far more complex, they are also significantly more expensive than regular EV chargers, as they employ advanced power conversion electronics to manage the vehicle’s energy flow.
For powering homes, bidirectional EV chargers also integrate devices to manage loads and isolate the house from the grid during power outages, a phenomenon known as islanding. The basic operating principle of a bidirectional EV charger is very similar to that of a bidirectional inverter, which serves as a backup power source in home battery storage systems.
What is the purpose of bidirectional charging?
Two-way chargers can be used for two different applications. The first and most noteworthy is Vehicle-to-grid, or V2G, designed to deliver or output energy to the grid when demand is high. If thousands of V2G-equipped vehicles are plugged in and activated, this has the potential to massively change how electricity is stored and produced. Electric vehicles have large and powerful batteries, so the total power of thousands of V2G-equipped vehicles could be enormous. Note that V2X is a term used to describe the three architectures discussed below:
I. Vehicle-to-grid or V2G – EV energy to support the grid.
II. Vehicle-to-home or V2H – EV energy used to power homes or businesses.
III. Vehicle-to-load or V2L – EVs can be used to power appliances or charge other electric vehicles.
The second use of a two-way EV charger is for Vehicle-to-home, or V2H. As the name suggests, V2H enables electric vehicles to be used like a home battery system to store excess solar energy and power your home. For example, a typical home battery system, such as the Tesla Powerwall, has a capacity of 13.5 kWh. In comparison, a typical electric vehicle has a capacity of 65 kWh, almost equivalent to five Tesla Powerwalls. Due to its large battery capacity, when combined with rooftop solar power, a fully charged electric vehicle can power an average household for several days or longer.
1. Vehicle-to-grid- V2G
Vehicle-to-grid (V2G) refers to the practice of feeding a small portion of the stored energy from an electric vehicle’s battery into the grid on demand. Participation in a V2G project requires a bidirectional DC charger and a compatible electric vehicle. Incentives exist, such as credits or reduced electricity rates for EV owners. V2G-equipped EVs also allow owners to participate in VPP (Vehicle Power Supply) programs to improve grid stability and provide power during peak demand periods.
Despite the hype, one of the challenges of rolling out V2G technology is the regulatory hurdles and the lack of standardized bidirectional charging protocols and connectors. Bidirectional chargers, such as solar inverters, are considered an alternative power generation method and must comply with all regulatory safety and outage standards in the event of grid failures. To overcome these complexities, some automakers, such as Ford, have developed simpler AC bidirectional charging systems that operate solely with Ford EVs to power homes, rather than supplying power to the grid.
2. Vehicle to Home- V2H
Vehicle-to-Home (V2H) is similar to V2G, but energy is used locally to power the home instead of being fed into the grid. This allows electric vehicles to operate like a regular home battery system, helping to improve self-sufficiency, especially when combined with rooftop solar power. However, the most obvious benefit of V2H is its ability to provide backup power during power outages.
For V2H to function properly, a compatible bidirectional inverter and other equipment are required, including an energy meter (with a current transformer) installed at the mains connection point. The current transformer monitors the energy flow into and out of the grid. When the system detects that your home is consuming grid energy, it signals the bidirectional EV charger to release an equivalent amount of electricity to offset any power drawn from the grid. Similarly, when the system detects energy output from a rooftop solar photovoltaic array, it diverts it to charge the EV, much like a smart EV charger.
To enable backup power during power outages or emergencies, the V2H system must detect islanding from the grid and isolate the home from the grid. Once islanded, the bidirectional inverter essentially operates as an off-grid inverter, powered by the EV’s battery. Additional grid isolation equipment, such as automatic contactors (ATS), is required to enable backup operation, just like the hybrid inverters used in solar cell systems.
3. Vehicle to Load- V2L
Vehicle-to-Load (V2L) technology is much simpler because it doesn’t require a bidirectional charger. Vehicles equipped with V2L have an integrated inverter that provides AC power from one or more standard outlets in the vehicle, which can be used to plug in any regular household appliance. However, some vehicles use a special V2L adapter that plugs into the electric vehicle’s charging port to provide AC power. In an emergency, an extension cord can be extended from the vehicle into the home to power basic loads such as lighting, computers, refrigerators, and cooking appliances.
V2L is used for off-grid and backup power
Vehicles equipped with V2L can use extension cords to provide backup power for operating selected electrical appliances. Alternatively, a dedicated AC transfer switch can be used to connect the V2L power directly to a backup distribution panel, or even to the main distribution panel.
Vehicles equipped with V2L can also be integrated into off-grid solar power systems to reduce or even eliminate the need for a backup generator. Most off-grid solar power systems include a bidirectional inverter, which technically can use power from any AC source, including vehicles equipped with V2L. However, it requires installation and configuration by a solar energy specialist or qualified electrician to ensure safe operation.
