Hot Sale 7kW Wall-mounted AC EV Charger TYPE 2 TYPE 1 GB/T Workplace AC EV Charging Station with 4G Wifi APP

Short Description:

This 7kW wall-mounted AC EV charger is the ideal energy replenishment solution for modern workplaces and commercial parks, offering seamless compatibility with Type 1, Type 2, and GB/T connector standards to flexibly accommodate diverse employee and visitor vehicles. Featuring intelligent app control and 4G/Wi-Fi connectivity, it supports remote monitoring, scheduled charging, and off-peak energy management, which effectively lowers operating and electricity costs while enhancing user convenience. Combined with an industrial-grade weatherproof enclosure and comprehensive active safety protections, it guarantees long-term, stable operation in both indoor and outdoor parking facilities, helping enterprises efficiently build green, intelligent, and modern workplace charging infrastructure.

Rated power: 7KW

Connectors: GBT TYPE2 TYPE1

Input Voltage: 22V

Output current (liquid cooled): 32A

Ingress Protection: IP65

Length of charging cable: 5m

Send email to us

Product Detail

Product Tags

Product Introduction

This 7kW wall-mounted AC charging station is the ideal solution for modern workplaces, offering intelligent APP control, 4G/Wi-Fi connectivity, and universal compatibility with Type 1, Type 2, or GB/T connectors to suit any fleet or employee vehicle.

EV Charger Parameters

Model	BH07K	BH11K	BH22K
Technical Features
Charging Capacity	Up to 7kW	Up to 11kW	Up to 22kW
Input/Output Power	220VAC±20% 50/60Hz-32A 1phase	380VAC±20% 50/60Hz-16A 3phase	380VAC±20% 50/60Hz-32A 3phase
RCD	30mA Type B and DC 6mA RCD function
Standby Power	<3W
Measuring Accuracy	1%
Communication	WiFi/Bluetooth, 4G, OCPP1.6 J (Optional)
User Interface	LED / LCD(4.3″) / RFID
Certificate/Compliance	CE / EN / IEC 61851-1:2017
Charging Interface	GBT / Type2 cable length 5m (customizable)
Special Protection	Over current, Residual current, Ground, Surge, Over/Under voltage, Over/Under frequency, Over/Under temperature protection
Physical Properties
Protection	Ip54, IK10
Enclosure	Plastic PC940
Front Panel	PC
Installation	Wall-mount/Pole-mount
Cooling	Natural cooling
Operating Temperature	-30 °C to +55°C
Humidity	Max.95% (non-regulating)

Smart Charging for the Modern Workplace

Boost your facility’s sustainability and employee convenience with a charging solution designed for professional environments:

Versatile Compatibility: Available with multiple connector options (Type 1, Type 2, or GB/T), ensuring your charging infrastructure can handle a wide range of electric vehicle brands.
Advanced Connectivity: Built-in 4G and Wi-Fi allow for real-time monitoring, remote power management, and seamless data logging via an intuitive smartphone app.
Workplace Efficiency: Features smart scheduling to optimize energy usage during off-peak hours, helping to reduce electricity costs while ensuring vehicles are ready for the daily commute.
Durable & Professional Design: The sleek, wall-mounted enclosure is built for professional aesthetics, while its IP65-rated construction ensures reliability and weather resistance for both indoor and outdoor parking facilities.

Key Technical Specifications

• Output Power: 7kW (32A)
• Connectivity: 4G / Wi-Fi / Ethernet / OCPP supported
• User Interface: 7-inch LCD touchscreen with RFID authentication
• Protection: Comprehensive electrical safeguards (leakage, overvoltage, short-circuit, and thermal protection)
• Installation: Flexible wall-mounted or optional pole/floor-mounted configurations

Scale Your Green Infrastructure

Equipping your workplace with professional-grade charging is a key step toward reducing your corporate carbon footprint and attracting eco-conscious talent. As a factory-direct source, we provide customized solutions including OEM branding, site-specific installation guidance, and technical support to integrate with your existing facility management systems.

FAQ

Q1 1. Why choose our products?

China BeiHai Power is located in Jiangxi of China. The company is a comprehensive service provider that integrates R & D, production, sales, construction, after-sales and operation with the main products of new energy electric vehicle charging equipment, pay special attention to product quality, there is a strict quality inspection system to ensure that each product before shipment will be tested. Business scope sales to North, southern Europe, western Europe, northern Europe, Eastern Europe, Africa, South, East Asia, Southeast Asia.

Q2 2. What can you buy from us?

AC EV Charging Station, DC EV Charging Pile, Portable Ev Charging Station, Split DC EV Charging Pile, EV Charging Gun.

Q3 3. How can we guarantee quality?

We have CE and ISO certification, and our company has a strict quality check system which ensures that our products achieve consistent quality standards, each product will be tested before shipment.

Q4 4. Can I customize my own logo?

Yes, OEM and ODM service are available. We also have professional design team for you if you need.lt;/div>

Q5 5. What is your terms of packing?

Generally, we pack our goods in brown cartons or wooden boxes. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.

Q6 6. What is your terms of payment?

T/T 50% as deposit, and 50% before delivery. We’ll show you the photos of the products and packages before you pay the balance.
