30KW 40KW 50KW 60KW On Grid Inverters

Short Description:

On-grid inverter specifications include single-phase 220-240v, 50hz; three-phase 380-415V 50hz; single-phase 120v/240v, 240v 60hz and three-phase 480v.

Product features:
Efficiency varies between 98.2-98.4%;
3-6kW, maximum efficiency up to 45 degC;
Remote upgrade and maintenance;
AC/DC built-in SPD;
150% oversizing and 110% overloading;
CT/Meter compatiblity;
Max. DC input 14A per string;
Lightweight and compact;
Easy to install and setup;

Send email to us

Product Detail

Product Tags

Description

Grid tie (utility tie) PV systems consist of solar panels and an on grid inverter, without batteries.
The solar panel provides a special inverter that directly converts the DC voltage of the solar panel into an AC power source matching the power grid. Extra power can sale to local city grid to reduce your home electricity fee.
It is an ideal solar system solution for private homes,have a full range of protection features; to maximize the benefits at the same time, greatly enhance the reliability of the product.

Specifications

Model	BH-OD10KW	BH-OD15KW	BH-ID20KW	BH-ID25KW	BH-AC30KW	BH-AC50KW	BH-AC60KW
Max Input Power	15000W	22500W	30000W	37500W	45000W	75000W	90000W
Max DC Input Voltage	1100V
Start-up Input Voltage	200V	200V	250V	250V	250V	250V	250V
Nominal Grid Voltage	230/400V
Nominal Frequency	50/60Hz
Grid Connection	Three Phase
No. of MPP Trackers	2	2	2	2	3	3	3
Max. input current per MPP tracker	13A	26/13	25A	25A/37.5A	37.5A/37.5A/25A	50A/37.5A/37.5A	50A/50A/50A
Max. short-circuit current per MPP tracker	16A	32/16A	32A	32A/48A	45A	55A	55A
Max output current	16.7A	25A	31.9A	40.2A	48.3A	80.5A	96.6A
Max Efficiency	98.6%	98.6%	98.75%	98.75%	98.7%	98.7%	98.8%
MPPT Efficiency	99.9%
Protection	PV array insulation protection, PV array leakage current protection, Ground fault monitoring, Grid Monitoring, Island protection, DC monitoring, Short current protection etc.
Communication Interface	RS485(standard); WIFI
Certification	IEC 62116, IEC61727, IEC61683, IEC60068, CE, CGC, AS4777, VDE4105, C10-C11, G83/G59
Warranty	5years, 10years
Temperature Range	-25℃ to +60℃
DC Terminal	Waterproof Terminals
Demension (HWD mm)	425/387/178	425/387/178	525/395/222	525/395/222	680/508/281	680/508/281	680/508/281
Approx Weight	14kg	16kg	23kg	23kg	52kg	52kg	52kg

Workshop

1111 workshop

Packing and Shipping

shipping

Application

Real-time power plant monitoring and smart management.
Convenient local configuration for power plant commissioning.
Integrate Solax smart home platform.
application
